ENTEL Marine
Rugged, designed for gloved hand use and with exceptionally loud audio, Entel’s HT commercial grade portable radios are specifically designed to withstand the
everyday rigours of the outdoor workplace.
The Entel HT700 Series 2.0 ‘Entry’ models provide instantaneous Push-To-Talk communications, with ‘Advanced’ models adding extra features including Individual & Group calling, Lone-Worker protection, Text messaging etc.
Environmental protection to IP68 (2 Meters for 4 hours)
The practical HT700 Series 2.0 portables enjoy an IP68 (2 Meters for 4 hours) rated construction, which means that they are dust protected and fully Submersible.
MILSTD 810C/D/E/F
Meeting MIL-STD 810C/D/E/F and providing commercial grade construction for a tough, enduring performance. Entel’s HT700 Series 2.0 portables conform to stringent standards, enabling them to withstand the everyday rigours of shock, vibration and the corrosive effects of dust and moisture, ensuring many years of trouble free use.
2000mAh Li-Ion battery
HT700 Series 2.0 portables are supplied with the latest intelligent Lithium-Ion battery technology as standard. One key advantage of Lithium-Ion battery technology is the way it eliminates ‘memory effect’, meaning that there is no need to fully discharge your battery before recharging. As a result of this, you are assured of a full charge each and every time you take your Entel battery from its charger.
Flash upgradeable to add future features
Entel adds and improves features on its HT700 radios by way of software updates. Using Flash Upgrade technology your Entel HT700 radios can be upgraded by your Dealer at any time.
Robust accessory socket
The socket has been specifically designed so that when an accessory is secured to the portable, the connection can withstand any amount of punishment; from dropping to careless misuse. Furthermore, the securing bolt incorporates a shearing point to protect the connector.
Channels
All non-display HT700 portables provide 16 programmable channels. Display portables provide 255 programmable channels.
| Frequency Range | 136 – 174MHz |
| Channels | Non LCD 16 Channels, LCD 255 channels |
| Channel Spacing | 12.5 kHz / 25 kHz |
| Communication Method | Simplex / semi duplex |
| Antenna Impedance | 50 ohm |
| Antenna | Whip / stubby |
| Battery Type | 2000 mAh Li-Ion battery pack |
| Power Supply Voltage | 7.4V DC |
| Current Drain (nominal) | 40mA |
| Duty Cycle (5/5/90) | 12.5 hours |
| Microphone | Internal condenser microphone |
| Construction | MIL-STD 810C/D/E/F |
| IP Rating | IP68 (2 meters depth for 4 hours) |
| Operating Temperature | -20° to +55°C |
| Size (mm) | 59.5(W) x 130(H) x 37(D) |
| Weight | 277g with battery and aerial |
Transmitter
| Power Output | High – 5W VHF, 4W UHF, & Low – 1W |
| Modulation | 8K0G3E/16K0G3E |
| Oscillator Method | PLL |
| Frequency Stability | 2.5PPM |
| Maximum Deviation | ±2.5 kHz(Narrow)/ ±5 kHz(Wide) |
| Audio Distortion | < 5% (1 kHz 60%) |
| Spurious Emission | -68 [dBc] |
| Hum & Noise | -40 [dB] |
Receiver
| Receiver Type | Double Super Heterodyne type |
| Sensitivity | -0.25uV (12dB SINAD) |
| Frequency Stability | 2.5PPM |
| Spurious Rejection | -60 dB |
| Adjacent Channel Selectivity | -60 dB (Narrow) , -70 dB (Wide) |
| Distortion | < 5% (1 kHz 60%) |
| Hum & Noise | -40 dB |
| Audio Output | 1W |
