ICOM IDAS DPMR
DAS dPMR is our solution for ETSI dPMR standard compatible radios. See how IDAS dPMR radios can provide features and benefits for your business communication needs.
Selective call and group call:
Radio to radio, radio to group and radio to all users calls are supported.
Status call:
32 preprogrammed status messages can be sent and received. The status call can be used as a trigger for special functions such as ambience listening, remote stun/kill/revive and GPS data delivery.
Transparent data call:
This function uses a dPMR radio as a data modem allowing data communication on a 6.25kHz channel such as for a remote telemetry system or data applications.
GPS data delivery:
Sends GPS position data with Status, SDM and emergency calls. Position data can be used for GPS-based vehicle management applications.
Emergency call:
The highest priority type of call. In a dPMR Mode 3 system, the network will attempt to connect this type of call as quickly as possible.
Pre-emptive emergency:
If all traffic channels are busy, this call service clears down the existing call and gives the highest priority for the emergency call.
Ambience listening:
The ambience listening function allows the dispatcher to turn on the PTT from a remote location and transmit anything the microphone hears for a preprogrammed period.
Remote kill:
This function disables a lost or stolen radio over the air, eliminating security threats from undesired listeners.
Remote stun/revive:
The remote stun function temporary locks out a radio until the revive command is received, or the user password is entered.
Call back (Radio function):
Up to ten missed incoming calls can be stored to return the call later.
Call queue:
If a called party or channel is busy, the call queue automatically connects the call when it becomes available.
Digital voice scrambler:
A built-in digital voice scrambler provides about 32,000 codes scrambler for secure conversations.
ANI (Automatic number identification):
The ANI function shows the alias ID number on the LCD while receiving a call, allowing the radio user to identify who is calling.
Late entry:
If a group call is in progress when a member of the group turns on the radio or comes into the radio coverage area, this function shows the caller’s name, and allows the user to join the conversation.
- IDAS 6.25kHz digital functions
- IDAS digital ready version available
- Improved voting function
- Lone worker function
- Full dot-matrix display
- 512 memory channels
- Detachable front panel with optional RMK-3 and separation cable
- BIIS 1200 compatible
- Multiple signalling as standard
- MIL-Spec rugged construction
- 2 Year warranty on transceiver
- Built-in audio compander
- Ignition sensing line (pig tail)
- Microphone hanger action programmable (Scan, monitor, priority channel)
- Power on password
- ±1.0ppm frequency stability
- Embedded ESN
- D-SUB 25 pin ACC connector for connecting various external devices.
- Back to back repeater connection between the IC-F5062* series radios
